| TRF1 | |
|---|---|
) French soldiers prepare to fire a TRF1 | |
| Type | towed howitzer |
| Place of origin | France |
| Service history | |
| In service | French Army |
| Used by | See Users |
| Wars | Gulf War[1] |
| Specifications | |
| Mass | 10.52t |
| Length | 10.0 m (32 ft 10 in) |
| Barrel length | 6.2 m (20 ft 4 in) L/40 |
| Width | 3.09 m (10 ft 2 in) traveling |
| Height | 1.79 m (5 ft 10 in) traveling |
| Crew | 8 |
| Calibre | 155 mm (6.1 in) NATO |
| Carriage | wheeled Split-trail |
| Elevation | -6° to +66° |
| Traverse | 27° left / 38° right[2] |
| Rate of fire | 3 shots in 15 s., 6 shots/min. (because it is necessary to let the tube cool down) |
| Effective firing range | 24 km (15 mi) with high-explosive shells 30 km (19 mi) with long-range ammunition |
The Tr-F1 is a 155mm French towed howitzer produced by Nexter (ex Giat Industries) and used by the French Army.
Performance
- Setting out of battery: 2 min
- Crossing of slopes of 60%, fords of 1.20m.
- Horizontal field of fire: 445mil to the left, 675mil to the right.
- Hydraulic aiming
Ammunition
- Capacity of tractor: 56 shots, 32 on pallets and 24 in rack.
- Can fire all 155 mm ammunition (the normal ammunition is the high-explosive shell).
- Casings are combustible, which improves rate of fire: there is nothing to extract before reloading.
Operators
)
Map of TRF1 operators in blue
Current operators
France - 105 delivered,[2] 43 as of 2016[3]
Cyprus - 12 delivered in 1991[4][5]
Saudi Arabia - 28 delivered in 1990-1991[4]
Senegal - 8 delivered in 2011[4][6]
