| M2 Flamethrower | |
|---|---|
) A soldier from the 33rd Infantry Division uses an M2 flamethrower. | |
| Type | Flamethrower |
| Place of origin | United States |
| Service history | |
| In service | 1944–1978 |
| Wars | World War II Korean War Vietnam War |
| Production history | |
| Designer | US Army Chemical Warfare Service |
| Designed | 1940–41 |
| No. built | 14,000 (M1A1) |
| Variants | M2A1-2, M2A1-7 |
| Specifications | |
| Mass | 43 lb (19.5 kg) empty 68 lb (30.8 kg) filled |
| Crew | 1 |
| Rate of fire | Around 0.5 US gal (1.9 l) a second |
| Effective firing range | 65 1&fras1;2 ft (20.0 m) |
| Maximum firing range | 132 ft (40 m) |
| Feed system | Two, 2 US gal (7.6 l) Napalm/gasoline tanks (fuel) One Nitrogen tank (propellant) |
| Sights | None |
The M2 flamethrower was an American man-portable backpack flamethrower that was used in World War II. It was the successor to the M1 and M1A1 flamethrowers. Although its burn time was only around 7 seconds and the flame was only effective out to around 20–40 meters, it was still a useful weapon. However, with the arrival of flamethrower tanks, the need for flamethrower-carrying infantrymen to expose themselves to enemy fire was greatly reduced.
Though some M2s were sold off, the majority were scrapped when they were declared obsolete.
Variants of the M2
The M2 was the WWII model had hexagonal gas caps and hourglass frames. It was also called the M2-2, M2 for the tank groups and -2 for the wand type.
The M2A1-2 is the variation of the M2 devised during the Korean War. These had straight sided backpack frames, vented gas caps, a cylinder sized regulator and a safety valve. These are much more common today than WWII models.
M2A1-7 was a flamethrower used by the American troops during the Vietnam War. It is the updated version of the M2A1-2 unit used during The Korean War.
It has four controls:
- Back of the rear grip: firing safety catch.
- Front of the rear grip: firing trigger.
- On top of the front part: igniter safety catch
- Under the front part: igniter trigger.
The M9A1-7 was the most common model used in Vietnam and is much lighter and easier to use. Tanks for this weapon are commonly found, but most wands were destroyed after the Vietnam war.
Some U.S. Army flamethrowers have a front handgrip with the same shape as the rear handgrip. In these models the igniter controls are on the front handgrip, arranged in the same way as the rear handgrip controls. The M2 was replaced by the M9A1-7 flamethrower which was used in Vietnam. The M9A1-7 was replaced by the M202A1 FLASH.
Operators
)
Former operators
.svg.png)
Australia[1]
Brazil
China
Republic of China (World War II)
Japan (after World War II for the JSDF; later replaced by a Japanese made flamethrower based on the M2)[2]
Philippines
United States
Indonesia
Malaysia
Thailand
.svg.png){kind=small}
Gallery
Two CGI views of a man with an M2A1-7 U.S. Army flamethrower. The two big tanks contain the fuel. The small tank contains the pressurizing gas (nitrogen).
M2A1 flamethrower.
M2A1 flamethrower used by the Republic of China during the China-Burma-India Theater.
)
)
)
